APM-J901-Z-WS Dome IP Camera
New Feature:
> Supporting 3x Optical Zoom
> 4” compact design
> Iphone APP downloadable (app : Apexis IP Control)
> Support Gmail/Hotmail function
> 8 preset positions monitoring
> Free DDNS for Remote viewing
> Freely control alarm sound ON/OFF
> Freely control alarm record ON/OFF
> Up to 13 languages for worldwide users
Basic Feature:
> MJPEG video compression format
> Support two-way audio function
> Freely control upload image to FTP
> Freely control Pan/Tilt angle by software
> Freely control Pan/Tilt speed by software
> Support up to 9 users online simultaneously
> Motion detection alert with snapshots via email
> Allow remote view & record from anywhere anytime
> Multi-level user management with password protection
> Wi-Fi compliant with wireless standards IEEE 802.11b/g
> Support both WEP & WPA WPA2 encryption for wireless
> Support Mobile phone login from User Interface via browser directly
> Support IE, Safari, Firefox, Google chrome browser or any other standard
browsers
| Specification: | Model: APM-J901-Z-WS | |
| Image Sensor | Image Sensor | 1/4" Color CMOS Sensor |
| Display Resolution | 640 x 480 Pixels(300k Pixels) | |
| Lens | 3x Optical Zoom(4mm-9mm) | |
| Mini. Illumination | 0.5Lux, F2.0 | |
| Lens Type | Glass Lens | |
| Viewing Angle | 30.7°~ 69° | |
| Audio | Input | 1 channel audio input |
| Output | 1 channel audio output | |
| Audio Compression | ADPCM | |
| Video | Image Compression | MJPEG |
| Image Frame Rate | 15fps(VGA),30fps(QVGA) | |
| Resolution | 640 x 480(VGA), 320 x 240(QVGA) | |
| Flip Mirror Images | Vertical / Horizontal | |
| Light Frequency | 50Hz, 60Hz, Outdoor | |
| Video Parameters | Brightness, Contrast | |
| Communication | Ethernet Interface | 10Base-T/100Base-TX Ethernet Port |
| Supported Protocol | TCP/IP, DHCP, SMTP, HTTP, DDNS, UPNP, PPPoE, FTP, DNS | |
| Wireless Standard | IEEE 802.11b/g | |
| Data Rate | 802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.) | |
| Wireless Security | WEP & WPA WPA2 Encryption | |
| Physical | Pan/Tilt Angle | Horizontal:355° & Vertical: 90° |
| Alarm Input | 1 Channel on/off Input | |
| Alarm Output | 1 Channel relay Output | |
| Dimension | 165*195*130 mm | |
| Power | Power Supply | 0° ~ 55°C |
| Power Consumption | 20% ~ 85% non-condensing | |
| Environment | Operate Temper. | - 25°C ~ 55° |
| Operating Humidity | 0% ~ 90% non-condensing | |
| Storage Temper. | 2.0GHZ or above (suggested 3.0GHz) | |
| Storage Humidity | 256MB or above (suggested 1.0GHz) | |
| PC System Requirements | CPU | 64M or above |
| Memory Size | Microsoft Windows 2000/XP/Vista/7 | |
| Display Card | IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers | |
| Supported OS | CE, FCC, RoHS | |
| Browser | Limited 1-year warranty | |
